SV series single stage rotary vane vacuum pump is a reliable, durable, economical and adaptable range of vacuum pumps.
In the circular pump body, is an air suction valve and exhaust valve (stator). The vanes are equipped with an eccentric slot in the rotor. The vane blades divide the pump chamber into three parts. The volume of the pump chamber keeps changing periodically as the rotor rotates to finish the process of gas suction, compression and elimination.
| Model | Pump speed (m3/h) | Motor Power (KW) | Inlet Diam (inch) | Rotary speed (rpm) | Oil Capacity (L) | G.W (kg) | Noise dB (A) | Dimensions (mm) | |
|---|---|---|---|---|---|---|---|---|---|
| 50HZ | 60HZ | ||||||||
| SV-010 | 10 | 12 | 0.37 (3ph) 0.55 (1ph) | G1/2 | 1400 | 0.5 | 20 | 64 | 405*253*210 |
| SV-020 | 20 | 24 | 0.75 (3ph) 0.90 (1ph) | G1/2 | 2800 | 0.5 | 20 | 64 | 405*253*210 |
| SV-025 | 25 | 30 | 0.75 (3ph) 0.90 (1ph) | G1/2 | 2800 | 0.5 | 22 | 64 | 405*253*210 |
| SV-040 | 40 | 48 | 1.5 (3ph) 2.2 (1ph) | G11/4 | 1400 | 1.0 | 50 | 67 | 660*300*270 |
| SV-063 | 63 | 75 | 2.2 | G11/4 | 1400 | 2.0 | 83 | 68 | 695*420*295 |
| SV-100 | 100 | 120 | 3.0 | G11/4 | 1400 | 2.0 | 87 | 72 | 735*420*295 |
| SV-160 | 160 | 192 | 4.0 | G2 | 1400 | 4.5 | 152 | 74 | 805*520*410 |
| SV-200 | 200 | 240 | 5.5 | G2 | 1400 | 4.5 | 159 | 76 | 825*520*410 |
| SV-250 | 250 | 300 | 7.5 | G2 | 1400 | 7.0 | 230 | 76 | 1000*550*410 |
| SV-300 | 300 | 360 | 7.5 | G2 | 1400 | 7.0 | 236 | 76 | 1200*550*410 |
| SV-630 | 630 | 750 | 15.0 | DN100 | 960 | 35 | 620 | 75 | 1630*1300*980 |
| SV-750 | 750 | 900 | 18.5 | DN100 | 1150 | 35 | 640 | 76 | 1630*1300*980 |
